HDx24 Hardware Interfaces

this section describes the characteristics and operation of all connectors on the hd224 and hd1024 power connector the power connector for the hd224 and hd1024 is rated for 12v\@1 5a the plug is a 3 5mm barrel power connector 3 5mm audio connector the hd224 and hd1024 have a combination analog/optical audio jack to transmit a digital audio signal, use an optical audio cable analog and digital audio cannot be transmitted simultaneously the full scale voltage output of the analog audio is 2v rms the minimum load impedance is 32w the analog audio connector has the following pinout tip left audio ring right audio sleeve ground for audio signal 3 5mm ir input / output the ir blaster generates or receives a space encoded nec or pronto hex signal the two transported bit values of the signal (0 and 1) are encoded using differing lengths of low time ir pulses the 3 5mm ir in/out port has the following pinout tip 3 3v\@50ma ring ir input sleeve ir output the sleeve is used as a ground during input operations 3 5mm rs 232 serial the uart (asynchronous serial) interface is a 3 5mm (1/8") jack that uses rs 232 levels for communication the receiver will tolerate input voltages between 30v and +30v, with anything below 3v interpreted as a logical 1 the transmitter drives +8v for logical 0 and 8v for logical 1 the default baud rate of the interface is 115200, with no parity, 8 data bits, and 1 stop bit these settings can be configured in the software the serial interface supports tx, rx, and ground only—rts/cts hardware flow control is not supported the following diagram illustrates the behavior of the tx and rx signal the 3 5mm serial port has the following configuration (from the perspective of the player) tip receive ring transmit sleeve ground brightsign players are dce devices, so communication with another dce device that uses a 3 5mm port would require a null modem cable or converter that transposes the tx/rx signals if the device communicating with the player is a dte device with a de 9 (more commonly referred to as db 9) serial port (performing asynchronous transmission), the serial cable should be wired as shown in the following diagram gpio the hd224 and hd1024 have a 12 pin gpio switch and led connector, which allows the player to control external leds or other devices requiring 24ma of current or less the gpio port is a standard design manufactured by phoenix contact, wurth electronics, and others pluggable gpio terminal blocks can be inserted into the gpio connector to make bare wire contacts (see here https //www digikey com/short/3101mw for an example part) these terminal blocks can be purchased from the brightsign store https //www brightsign biz/digital signage products/accessories/gpio terminal block if you wish to source your own terminal blocks, make sure to use 4 pin or 6 pin blocks (12 pin blocks are extremely difficult to remove from the gpio port) connect the led outputs to the led anode and connect the led cathode to the ground if you want to connect another device, then the output is capable of sourcing or sinking up to 3 3v at 24ma, but there is a series resistor of 100ω in each line the gpio also allows for connecting of external contact closures to the ground in order to connect a switch, connect one side of the switch to the switch input, and connect the other side to one of the ground pins on the gpio connector the connector can also supply 3 3v at up to 500ma to an external device the 3 3v output is polyfuse protected and can source up to 500ma if one brightsign player is driving the inputs on another brightsign player, then you can drive at most three inputs from one output the following calculations explain this limitation the gpio outputs have 100ω series resistors; the gpio inputs have 1k pullup resistors to 3 3v; and the input threshold is 2v high and 8v low the high voltage is not problematic, but the low voltage can be if there are too many inputs connected to one output 1 out driving 1 in v=3 3 100/(100+1,000)=0 3 1 out driving 2 in v=3 3 100/(100+500)=0 55 1 out driving 3 in v=3 3 100/(100+333 3)=0 76 1 out driving 4 in v=3 3 100/(100+250)= 94 (this is too high, so 1 output driving 3 inputs is the maximum) gpio pinout the following table illustrates the pinout of the gpio on the hd224 and hd1024 pin function pin function 1 gnd 7 gnd 2 3 3v 8 3 3v 3 button 0 9 button 4 4 button 1 10 button 5 5 button 2 11 button 6 6 button 3 12 button 7 the following schematic illustrates the pinout of the gpio connector example diagrams the following example diagrams demonstrate how led buttons can be wired to the gpio connector (in both 1 and 4 button configurations) https //archbee doc uploads s3 amazonaws com/0prk6so2dy9ldu77jb8d1/wbpszy9kfadioanmmel c phoenix 1button half rev b pdf https //archbee doc uploads s3 amazonaws com/0prk6so2dy9ldu77jb8d1/sdsztr boq4499qd8vq9w phoenix 4buttons rev b pdf rj45 lan the hd224 and hd1024 have an rj45 connector for 1000base t networking the maximum length for cat 5e cable is 100 meters; the allowed length can be higher or lower depending on the quality of the cable usb the hd1024 has one usb 2 0 type a port, which is capable of transfer speeds up to 480 mbit/s the maximum length for a usb cable is 5 meters the following table illustrates the pinout of the usb 2 0 type a host port pin description pin description 1 vbus 2 d 3 d+ 4 ground hdmi output the hdmi® out connector is used to send digital video and audio to hdmi enabled sink devices this connector is compatible with hdmi 2 0 devices, capable of outputting a maximum video resolution of 3840x2160x60p the following table illustrates the pinout of the hdmi connector pin description pin description 1 tx2p 2 ground 3 tx2n 4 tx1p 5 ground 6 tx1n 7 tx0p 8 ground 9 tx0n 10 txcp 11 ground 12 txcn 13 cec 14 nc 15 ddc scl 16 ddc sda 17 ground 18 +5v ddc 19 hpd (hot plug detect) pdf version https //archbee doc uploads s3 amazonaws com/aiw58 3npddpglgjivvls qfnedzormulpbt6smyrbn 20250623 223745 pdf
